Lite 80

WOOD-ALUMINUM WINDOWS AND DOORS

When the Frame Becomes a Balance of Aesthetics, Efficiency, and Durability

The LITE 80 Line is designed for those seeking a slender yet high-performing frame, capable of offering residential comfort, resistance to atmospheric agents, and an essential design. The internal wood provides warmth and naturalness, while the external ventilated aluminum protects over time without the need for invasive maintenance.

FAS Serramenti: Wood-Aluminum Windows and Doors - Lite 80

Wood Inside,
Protection Outside

The Lite 80 wood-aluminum frame combines the warmth of internal wood with the resistance of external aluminum, in a frame that is slender, elegant, and designed to last without invasive maintenance.

Featuring an 80 mm laminated wood structure, a ventilated aluminum exterior cover, and glazing units up to 44 mm, Lite 80 guarantees excellent thermal and acoustic insulation, total protection from rain, wind, and sun, with a minimal and contemporary aesthetic.

Ideal for those seeking efficiency and practicality in a reduced profile:

Homes in harsh climates or areas with high solar and acoustic exposure.
Residential projects aiming for high energy standards, such as CasaClima, NZEB, etc.
Buildings where architecture and sustainability must engage in a warm and noble language.

Technical Specifications

Profile Section

Fixed Frame: 61 x 80 mm
Operable Sash (Vent): 78 x 81 mm
Internal structure in laminated or solid wood.
External cover in extruded aluminum for protection against atmospheric agents, featuring a minimal interlocking profile.

Glazing

Pre-set for 32 mm single-chamber and 42 mm double-chamber glazing units.
Glass Types: Low-emissivity, selective, acoustic, safety, stratified.

Hardware

Hardware Type: Perimeter system, standard tilt-and-turn (anta-ribalta).
Security: Mushroom head anti-burglary locking points available upon request.
Adjustments: Height, depth, compression on the sash.
Hinges: Double-cup.

Serramenti in legno-alluminio - Lite 80 angolare

Gaskets

Number of Gaskets: 2

Surface Treatment

Wood treated with a four-coat water-based cycle.
Available wood colors: Stained, pigmented, and RAL lacquered.
Aluminum cover available in satin, embossed, metallic, or wood-effect finishes.

Indicative Technical Performance

Thermal Transmittance (Uw): Up to 1,1 W/m²K
Acoustic Reduction: Up to 40 dB
Air Permeability: Class 4
Water Tightness: Class E900
Wind Resistance: Class C4

Colors & Finishes

Wood Species

FAS Serramenti uses raw laminated wood of the highest quality, sourced from certified, sustainably managed forests, available in 4 wood species.

Pine

Larch

Red Grandis

Oak

Painting

Each wood species can be customized with matt finishes, brushed effect treatments, and a wide range of colors, to adapt perfectly to the style of every environment, enhancing it with elegance.
